JBL Professional Control 68HP 2-way Outdoor Pendant Mount Speaker - 250 W RMS

Print JBL Professional Control 68HP 2-way Outdoor Pendant Mount Speaker - 250 W RMS pageRequest Bulk Pricing CAMCOR ITEM NO. 319900775 | MFG. PART NO. JBL-C68HP
JBL Professional Control 68HP 2-way Outdoor Pendant Mount Speaker - 250 W RMS
JBL Professional Control 68HP 2-way Outdoor Pendant Mount Speaker - 250 W RMS
Zoom
Close WindowZoom
Alternate View

We will gladly send you a quote for this item. Please click the link below to fill out the form and receive the quote via FAX or e-mail.

Get Quote

Become a registered user and view prices on all products

Usually ships in 1-3 business days
Free ShippingQualifies for
FREE SHIPPING (?)

This item Qualifies towards Free Shipping!

Items marked with this Freight Saver symbol have FREE shipping (via UPS Ground Service within the Continental US) when $ 79.00 or more of designated Freight Saver items are purchased on the same internet order.

Camcor, Inc. uses parcel carriers including UPS and FedEx. UPS will NOT deliver to PO Boxes (can only be shipped via US Postal Service). For residential and business orders shipped by motor freight (truck) common carrier, normal delivery is curbside or loading dock (Dock to Dock Delivery) and NOT inside the home or business.

For any special request such as "in home", "inside building", "up elevators", "up stairs", "set up", "lift gate truck", the freight company will assess additional charges. Customers are responsible for any such charges.

Product Highlights
APPLICATIONS The Control 68HP is a very high output, full-range, two-way pendant-type loudspeaker that provides superb sound reproduction and very consistent, wide coverage for rooms with open ... More

Is This Item Right For Me? - Ask Our Experts
Phone 800.868.2462

WarningCalifornia Residents:
WARNING: Cancer and reproductive harm - See www.P65Warnings.ca.gov for more information.

Product Description

APPLICATIONS

The Control 68HP is a very high output, full-range, two-way pendant-type loudspeaker that provides superb sound reproduction and very consistent, wide coverage for rooms with open architecture ceilings, rooms with lively acoustics (ie, lowering the height of the speakers to increase the direct-to-reverberant sound ratio), and other locations where a pendant form factor is desired. The wide 110° coverage pattern allows for the use of fewer speakers, reducing the cost of the installed system without sacrificing performance.

High output, excellent sound quality coupled with stylish design and easy installation makes the Control 68HP ideal for a wide variety of applications including retail, restaurants, hotels, casinos, fitness centers, convention centers, exhibit spaces, conference rooms, atriums, museums, transit centers and other applications with open-ceilings, lively acoustics, or where the pendant form factor is desired for aesthetic reasons.

Control 68HP provides extremely consistent 110°constant directivity conical coverage. The coaxial driver's pole piece is internally milled to form a low-distortion throat while the cone forms the bell of a conically-contoured constant directivity horn, resulting in extremely consistent sound character throughout the entire listening area.

The Control 68HP includes a single-point mounting system for easy and secure suspension in open-ceiling applications. Two complete hanging cable systems are included, providing both main and safety suspension cables. Included are extra-long 4.5 m (15 foot) high tensile galvanized steel wire rope having spring clips for the loudspeaker end of the cable and UL listed cable fasteners for infinitely adjustable suspension height.

The system's 209 mm (8 in) low-frequency driver features a Kevlar™ reinforced cone and a large 50 mm (2 in) CCAW voice coil on a fiberglass voice coil former for high power and improved long-term reliability. The coaxially-mounted 25 mm (1 in) compression driver features a titanium dome with damped resonance and a Kapton™ voice coil former for enhanced long-term sound level capability combined with highfidelity sound quality.

The Control 68HP contains a high-quality 68 Watt multi-tap transformer for use on 70V/100V distributed loudspeaker lines, and is switchable for 8-ohm voice-coil direct operation.

Euro-style clip-in connectors allow for each wiring. For protected/covered outdoor applications, rubber boots are included to cover the input connectors, and an optional terminal cover (MTC-60PC) is available for direct-exposure locations.



Specifications

General Information
ManufacturerHarman International Industries, Inc
Brand NameJBL Professional
Product LineControl
Product Model68HP
Packaged Quantity1
Product TypeSpeaker
Technical Information
Crossover Type2-way
RMS Output Power250 W
PMPO Output Power1000 W
Woofer Driver Size8"
Woofer Driver MaterialKevlar
Tweeter Driver Size1"
Tweeter Driver MaterialTitanium Dome
Minimum Frequency Response52 Hz
Maximum Frequency Response17 kHz
Impedance8 Ohm
Sensitivity90 dB
Ingress Protection (IP) RatingIP44
Physical Characteristics
Box MaterialPolystyrene
Form FactorPendant Mount
DurabilitySplash Proof
Speaker InstallationOutdoor
Height13.6"
Diameter13.1"
Weight (Approximate)16.53 lb
Miscellaneous
Package Contents
  • C68HP Pendant Speaker
  • 2 x Suspension Cable Systems
  • 2 x 2-Pin Removable Locking
  • 2 x Rubber Covers
Application/Usage
  • Retail
  • Restaurant
  • Hotel
  • Casino
  • Convention Center
  • Conference Room
  • Atrium
  • Museum
  • Transit Center
  • Health Club
  • Environmentally FriendlyYes
    Environmental CertificationRoHS
