Black High-Performance EZ-Strip Broadcast Audio 22 AWG 1 Pair Shielded Cable

Print Black High-Performance EZ-Strip Broadcast Audio 22 AWG 1 Pair Shielded Cable pageRequest Bulk Pricing CAMCOR ITEM NO. 536005518 | MFG. PART NO. 22-1P-EZ-BLK
Black High-Performance EZ-Strip Broadcast Audio 22 AWG 1 Pair Shielded Cable
Black High-Performance EZ-Strip Broadcast Audio 22 AWG 1 Pair Shielded Cable
Zoom
Close WindowZoom
Alternate View

MSRP: 338.36
Savings: $33.83

Your Price: $304.53
Quantity

Free ShippingFREE
SHIPPING (?)

This item has Free Shipping!

Camcor, Inc. uses parcel carriers including UPS and FedEx. UPS will NOT deliver to PO Boxes (can only be shipped via US Postal Service). For residential and business orders shipped by motor freight (truck) common carrier, normal delivery is curbside or loading dock (Dock to Dock Delivery) and NOT inside the home or business.

For any special request such as "in home", "inside building", "up elevators", "up stairs", "set up", "lift gate truck", the freight company will assess additional charges. Customers are responsible for any such charges.

Product Highlights
Black High-performance EZ-strip broadcast audio 22 AWG 1 pair shielded cable. Product manufactured compliant to the requirements of UL444 for installations and applications in accordance with NEC ... More

Is This Item Right For Me? - Ask Our Experts
Phone 800.868.2462

WarningCalifornia Residents:
WARNING: Cancer and reproductive harm - See www.P65Warnings.ca.gov for more information.

Product Description

Black High-performance EZ-strip broadcast audio 22 AWG 1 pair shielded cable. Product manufactured compliant to the requirements of UL444 for installations and applications in accordance with NEC articles 725 and 800.

  • 7-strand annealed tinned copper conductors
  • Cellular polyethylene dielectric insulation
  • Tightly twisted and shielded
  • Semi-pressure extruded PVC jacket
  • shield bonded to the jacket for EZ-Stripping
  • NEC CM, CEC CMG FT4, RoHS compliant
  • 1000 foot spools

Back to Top

Specifications

Specifications

Cable Length304.8000 m
Cable Length30479.9990 cm
Cable Length1000 ft
Impedance72 ohm
Capacitance17 pF
TEMPERATURE RATING75 °C
Strand Gauge30 AWG
DCR14.8 ohms
Conductor Insulation Diameter0.050 inch
Conductor Insulation Thickness0.010 inch
Voltage300 Volts
Conductor Diameter0.030 inch
Current Draw2.8 Amps
AC Voltage300 Volts

Product Dimensions

Product Weight17 lbs
