Black Serial Digital RG6 Dual Shield 4.5 Ghz Coaxial Cable

Print Black Serial Digital RG6 Dual Shield 4.5 Ghz Coaxial Cable pageRequest Bulk Pricing CAMCOR ITEM NO. 536005722 | MFG. PART NO. 18-CMR-SD-BLK
Black Serial Digital RG6 Dual Shield 4.5 Ghz Coaxial Cable
Black Serial Digital RG6 Dual Shield 4.5 Ghz Coaxial Cable
Zoom
Close WindowZoom
Alternate View

MSRP: 825.48
Savings: $82.54

Your Price: $742.94
Quantity

Usually ships in 1-3 business days
Free ShippingFREE
SHIPPING (?)

This item has Free Shipping!

Camcor, Inc. uses parcel carriers including UPS and FedEx. UPS will NOT deliver to PO Boxes (can only be shipped via US Postal Service). For residential and business orders shipped by motor freight (truck) common carrier, normal delivery is curbside or loading dock (Dock to Dock Delivery) and NOT inside the home or business.

For any special request such as "in home", "inside building", "up elevators", "up stairs", "set up", "lift gate truck", the freight company will assess additional charges. Customers are responsible for any such charges.

Product Highlights
Black Serial digital RG6 dual shield 4.5 GHz coaxial cable. Product manufactured compliant to the requirements of UL444 for installations and applications in accordance with NEC articles 725, 800 and  ... More

Is This Item Right For Me? - Ask Our Experts
Phone 800.868.2462

WarningCalifornia Residents:
WARNING: Cancer and reproductive harm - See www.P65Warnings.ca.gov for more information.

Product Description

Black Serial digital RG6 dual shield 4.5 GHz coaxial cable. Product manufactured compliant to the requirements of UL444 for installations and applications in accordance with NEC articles 725, 800 and 820.

  • 18 AWG solid annealed bare copper conductor
  • Gas-injected cellular polyethylene dielectric
  • 100% coverage aluminum/poly/aluminum foil inner shield
  • 95% coverage tinned copper braid shield
  • Flame rated PVC jacket
  • 4.5 GHz sweep, very low loss, excellent SRL
  • NEC CMR, CEC CMR FT4, RoHS compliant
  • 1000 foot spools

Specifications

Specifications

Cable Length30479.9990 cm
Cable Length1000 ft
Cable Length304.8000 m
Impedance75 ohm
Capacitance16.2 pF
Temperature Range-20 to 75 °C
DCR (shield)2.9 ohms
VOP82 %
DCR6.4 ohms
SRL26 dB
SRL23 dB
SRL18 dB
Voltage300 Vrms
AC Voltage300 Volts

Product Dimensions

Product Weight42 lbs
